UltraCharge 160 80kW | Dual CCS2 Fast DC EV Charger | Evergy

Call for pricing

The Rolec UltraCharge 160 80kW is a dependable dual CCS2 DC charger for medium-traffic commercial locations. It balances cost, performance and grid load.

80kW DC output with 2x CCS2 connectors
Power shared dynamically between two vehicles
Touchscreen interface with full OCPP compatibility

Why We Recommend This Product: It delivers reliable, fast charging without overloading infrastructure—ideal for businesses and car parks.

Need installation? Call 01844 393939 now!

SKU: EVDC2020

Free and easy returns | Easy to Install | Professional Installers Available

UltraCharge 160 80kW: Efficient DC Charger for Everyday Commercial Use

The Rolec UltraCharge 160 (80kW) offers fast, dual-vehicle DC charging for everyday commercial applications. With two CCS2 connectors and up to 80kW output, this charger is perfect for public car parks, business premises, and medium-traffic EV hubs.

Dual CCS2 with Smart Load Distribution

This unit supports two EVs simultaneously via 2x CCS2 connectors. It delivers 80kW total output with dynamic load balancing based on real-time demand—so both cars charge efficiently without grid strain.

80kW total DC output
Dynamic sharing across 2x CCS2 ports
Supports parallel or single fast-charging sessions

Ideal for Everyday Commercial Settings

Smaller than full-speed chargers but more capable than 30kW units, the 80kW model fits the needs of medium-traffic commercial or public sites. It comes with a 15.6” touchscreen, LED status lights, and supports app or contactless access.

Engineered for Longevity

The unit is weatherproof, air-cooled, and built with surge, overcurrent and smoke protection. Its modular design allows easy maintenance and future upgrades.

Why Evergy Recommend This Product

Strikes the balance between cost and performance
Dual CCS2 ensures flexibility for users
Perfect for growing EV charging networks

Ideal For

Retail car parks, hotels, offices, small fleet bases, and growing EV businesses.

Key Specifications

Output: 80kW (DC)
Connectors: 2x CCS2
Interface: 15.6” touchscreen + LED status ring

See ‘Specification’ tab or product datasheet for full details.

Delivery

Includes free UK delivery. Larger orders may require pallet handling. See our delivery page for more info.

Compare with Other Models

UltraCharge 160kW – Maximum output
UltraCharge 60kW – Mixed connector setup
UltraCharge 30kW – For low-traffic sites

Complete your installation with the Rolec Root Mount Chargepoint Protector designed to safeguard posts and chargepoints alike.

Want help choosing the right charger? Speak to Evergy or call 01844 393939.

Attribute name	Attribute value
Finish	All-weather powder-coated
Cable Length	5m (4.5m exposed, extended 7m cables available)
User Interface	15-inch HD touchscreen display
RFID Reader	ISO 14443 A + B, ISO/IEC 15693, Mifare 1
NFC Contactless Payment Terminal	Optional
Plug & Charge	ISO 15118
Status Indicator	RGB LED
Dynamic Power Balancing	Advanced
Load Management	Static and dynamic (software configurable)
AC Input Voltage	400V ± 10%
Input Frequency	50/60 Hz
Input Type	3P + N + PE
Power Factor	0.99
Connector Options	CCS2 (other configurations available)
DC Output Voltage Range	200 to 1000 VDC
Maximum Output Current	300A
Peak Efficiency	96%
Communications	4G, RJ45 Ethernet connection, OCPP 1.6J, OCPP 2.0.1 upgradable
Body Material	304 Stainless steel
EMC Compliance	Class A (industrial)
Warranty	2 years (extended warranty available upon request)
Ingress Protection	IP55
Rated Power	DC up to 160kW (model dependent)
Certifications	CE, UKCA, TUV, TR25, RCM
Enclosure Protection	IK10
